Vibrating Machine

PRODUCT MODEL:
C4000 - Vibrating Machine for 70.7 mm Cube Moulds, 220-240 V 50 Hz
C4000/110 - Vibrating Machine for 70.7 mm Cube Moulds, 220-240 V 50 Hz

PRODUCT STANDARDS:
BS 4550
The Vibrating Machine is used for complies with BS 4550 standard the preparation and compaction of 70.7 mm mortar cube specimens . The mould table is mounted on four springs attached to an eccentric shaft which allows each sample to be vibrated at 12000 cycles per minute. There is a timer on it to preset time and it stops automatically in every 120 seconds.

Dimensions

460x460x840 mm

Weight (approx)

100 kg

Power

1100 W



  • Collecting tray
